Power Energy Appraisal Index
- Capacity for 30,000 cbm/year particle board production line |
|
Common AC motor |
380 |
V |
|
Voltage fluctuation frequency |
≤±5 |
% |
|
AC motor frequency |
50 |
Hz |
|
Range of fluctuation frequency |
≤±2 |
% |
|
Motor directly starting power |
≤18.5 |
kw |
|
Star triangle starting power |
>18.5 |
kw |
|
|
|
|
Note |
|
|
|
Large starting torque and hydraulic oil motor, will be also stared even less 18.5kw |
|
Motor power for production line |
|
|
Material preparing section |
Approx 690 |
kw |
|
Drying sieve section |
Approx 450 |
kw |
|
Glue blender section |
Approx 120 |
kw |
|
Forming pressing section |
Approx 370 |
kw |
|
Board trimming section |
Approx 450 |
kw |
|
Sanding section |
Approx 450 |
kw |
|
Air conveying and dusting section |
Approx 280 |
kw |
|
Some auxiliary equipment |
Approx 25 |
kw |
|
Glue making system |
Approx 70 |
kw |
|
Heating system (Including recirculation) |
Approx 250 |
kw |
|
Air pressing system |
Approx 130 |
kw |
|
Illuminating & others |
Approx 80 |
kw |
|
Total power |
Approx 2965 |
kw |
Note |
|
|
|
All above is just estimate power, for real power need will be according to finished line |
|
