Technical And Economic Appraisal Index
- Capacity for 30,000 cbm/year particle board production line |
No. |
Item |
Unit |
Value |
Note |
1 |
Capacity |
|
Particle Board |
m3/d |
150 |
Thickness is 19mm |
2 |
Board Specification |
|
Particle Board |
mm |
2440*1220*(8-25) |
|
3 |
Working Regulation |
|
Yearly working days |
Day |
300 |
|
|
Daily working time |
Hour |
22.5 |
Effective working time |
4 |
Material Consumption |
|
Wooden material |
T/year |
~32000 |
Bone dry |
5 |
Main Auxiliary Material |
|
Urea-formaldehyde Resin |
T/year |
~3000 |
Solid content is 100% |
|
Amm onium chloride |
T/year |
~40 |
Concentration 97% |
|
Paraffin |
T/year |
~190 |
Solid |
6 |
Power consumption |
|
|
|
|
Process water |
m3/h |
~8 |
Exclude boiler & fire protection water |
|
Compressed air |
Nm3/h |
~6 |
|
|
Heat energy |
kcal/h |
450×104 |
Based on water content 80% |
7 |
Installed electric energy |
kW |
~1800 |
Exclude boiler, glue making etc |
8 |
Works area |
m2 |
6000 |
|
9 |
Material storage area |
|
30000 |
Available for three moths using |
10 |
Persons in works |
Persons |
90 |
Subject to local condition |
|
|
